LED 7 Segment display

| 7 segment led display >> SINGLE DIGIT >> 1.00 inch single seven segment led display , bi-color

Specification

SeriesBL-S100C-12xx,BL-S100D-12xx
Apperance:1.00 inch digit height(25.40mm)
Dimension: 24.00*34.00mm
Datasheet:

1.00 inch single seven segment led display 1.00 inch digit height(25.40mm) widthheight: 24.0034.00mm Single decimal point Single or Double LED chip per segment Bi-color selected; Common anode or common cathode selected Low Current Operation cellen

View Clear drawing

Part No CC. Part No CA. Color Wave length (V) typ (V) Max Bright (mcd)
BL-S100C-12SG BL-S100D-12SG Green 570 2.2 2.5 92
BL-S100C-12SG BL-S100D-12SG Hi Red 660 1.85 2.2 80
BL-S100C-12EG BL-S100D-12EG Orange 635 2.1 2.5 92
BL-S100C-12EG BL-S100D-12EG Green 570 2.2 2.5 92
