LED 7 Segment display

7 segment led display >> SINGLE DIGIT >> 2.30 inch single seven segment led display

Specification

SeriesBL-S230E-11,BL-S230F-11
Apperance:2.30 inch digit height(56.80mm)
Dimension: 47.80*69.70mm
Datasheet:

2.30 inch single seven segment led display 2.30 inch digit height(56.80mm) widthheight: 47.8069.70mm Bi-color selected; Single decimal point Common anode or common cathode selected Low Current Operation excellent Character Appearance High Light Outpu

View Clear drawing

Part No CC. Part No CA. Color Wave length (V) typ (V) Max Bright (mcd)
BL-S230E-11H BL-S230F-11H Red 700 2.25 2.6
BL-S230E-11UR BL-S230F-11UR Ultra Red 660 1.85 2.2 250
BL-S230E-11S BL-S230F-11S Hi Red 660 1.85 2.2 150
BL-S230E-11D BL-S230F-11D Super Red 660 1.85 2.2 220
BL-S230E-11E BL-S230F-11E Orange 635 2.1 2.5 165
BL-S230E-11UE BL-S230F-11UE Ultra Orange 630 2.1 2.5 170
BL-S230E-11UY BL-S230F-11UY Ultra Yellow 590 2.1 2.5 170
BL-S230E-11Y BL-S230F-11Y Yellow 585 2.1 2.5 165
BL-S230E-11UG BL-S230F-11UG Ultra Green 574 2.2 2.5 220
BL-S230E-11G BL-S230F-11G Green 570 2.2 2.5 165
BL-S230E-11PG BL-S230F-11PG Ultra Pure Green 525 3.8 4.5 245
BL-S230E-11UB BL-S230F-11UB ultra Blue 470 3.8 4.5 150
BL-S230E-11B BL-S230F-11B ultra Blue 470 3.8 4.5 130
BL-S230E-11W BL-S230F-11W Ultra White / 2.7 4.2 180

[Print] [Return]

Specification

PDF DATASHEET
