LED 7 Segment display

7 segment led display >> SINGLE DIGIT >> 0.60 inch single seven segment led display

Specification

SeriesBL-S60C-11,BL-S60D-11
Apperance:0.60 inch digit height(15.00mm)
Dimension: 18.00*25.00mm
Datasheet:

0.60 inch single seven segment led display 0.60 inch digit height(15.00mm) widthheight: 18.0025.00mm Double decimal point Single LED chip per segment Common anode or common cathode selected Low Current Operation excellent Character Appearance High L

View Clear drawing

Part No CC. Part No CA. Color Wave length (V) typ (V) Max Bright (mcd)
BL-S60C-11H BL-S60D-11H Red 700 2.25 2.6 4.5
BL-S60C-11UR BL-S60D-11UR Ultra Red 660 1.85 2.2 75
BL-S60C-11S BL-S60D-11S Hi Red 660 1.85 2.2 45
BL-S60C-11D BL-S60D-11D Super Red 660 1.85 2.2 67.5
BL-S60C-11E BL-S60D-11E Orange 635 2.1 2.5 48
BL-S60C-11UE BL-S60D-11UE Ultra Orange 630 2.1 2.5 50
BL-S60C-11UY BL-S60D-11UY Ultra Yellow 590 2.1 2.5 50
BL-S60C-11Y BL-S60D-11Y Yellow 585 2.1 2.5 48
BL-S60C-11UG BL-S60D-11UG Ultra Green 574 2.2 2.5 67.5
BL-S60C-11G BL-S60D-11G Green 570 2.2 2.5 48
BL-S60C-11PG BL-S60D-11PG Ultra Pure Green 525 3.8 4.5 88
BL-S60C-11UB BL-S60D-11UB ultra Blue 470 3.8 4.5 75
BL-S60C-11B BL-S60D-11B ultra Blue 470 3.8 4.5 60
BL-S60C-11W BL-S60D-11W Ultra White / 2.7 4.2 75
